TrueGrid® CFD Model of an Inlet to a
Centrifugal Compressor
![](images/clear.gif)
Containing 200,000 nearly orthogonal hexahedral elements, this model was
constructed with a multiple block butterfly configuration. Some of the
geometry was imported and some built within
TrueGrid®.
Small elements in the boundary areas were required by the CFD code. A splitter
vane in the middle is carefully meshed.
