TrueGrid® CFD Grid of an Impeller - Zoomed

zoomed view of impeller grid

Zoom In

The geometry for this model was 10 digital flow paths across each blade. It took about 4 hours to create this grid using TrueGrid®. This mesh is for visualization. Usually a periodic portion is simulated. Selected faces of a replicated section are shown.
