TrueGrid® Hexahedral Mesh of Aluminum Flow About a Die

TrueGrid® grid of aluminum flow about a die

This all hex mesh was designed from a solids model. Aluminum is forced from the back of the model, as you view this picture. The holes in the mesh are for the braces of the die. The aluminum extrudes as a thin walled pipe with a planar section down the middle.
