Quarter Of Finite Element Mesh of Child Proof Cap

*
This child proof cap was modeled with hexahedral elements. The geometry was built in a solids modeler. The helical thread was easily modeled, with mesh lines which transition from inner radius to outer radius, using the projection method.
