TrueGrid® Hexahedral Mesh of a Tool Bracket
This simple model is constructed with three parts. The geometry consists of 10 surfaces built in TrueGrid®. There are 23,217 nodes and 17,502 brick elements. The quality of the mesh is completely under the control of the user.
