Mesh of a Racing Bike Chain

finite element mesh of racing bike chain

There are two different types of links in this chain. Correspondingly, there are two parameterized command files used to generate this chain, one for each type of link. A third command file is used which includes the two link files many times. Before each include, parameters are set which determine the position of each link.
